Our products are made up of four layers. The outermost layer is the protection layer, which shields the vinyl underneath. Next is the high-grade polymeric vinyl, which is backed by a pressure-sensitive acrylic adhesive. The final layer is a high-quality 130um plastic liner.
Material
High Grade Polymeric Calendared Vinyl Film
Fashionable, Stunning Color
Bubble-free Application
Slideable; Repositionable
Medium Stretchable
The Maximum is 30 %
Functions
▲ Standard Size & Appearance
Classification
Unit
Spec
Remark
Thickness
Top protected film
um
36±2%
PET/PVC
Surface materials
um
120±2%
High-grade PVC-Polymeric
Glue
um
30±2%
High-quality Solvent-based
Release liner
um
180±2%(paper)/ 130±2%(plastic)
－
Surface
－
Opaque
－
Width
mm
1520±0. 01%
－
Length
mm
1800+1%
－
Physical properties
▲ General Properties
Features
Test Method
Results
Release force N/25mm
25℃ and 50%
0.12
Initial tack g/25mm
under 26℃ and 64%, GB31125-2014
1360
Peel Strength N/25mm
25℃and 42%, GB/T2792-1998
7.05
Holding power(h)
25℃ and 50%, GB/T4851-1998
72.09
Shelf life
stored in +10°C to +20°C, relative humidity 50%, in original package, away from direct sunlight, clean and dry place
2 years
Time Limits
Must use it within 3 Months after you receive the wrap film
3 Months
Application temperature
/
+20℃ to +30℃
Aging Test 1
7 days under 65°C
No adhesive residue with heat
Aging Test 2
10 days under 65°C
No adhesive residue without heat
Shrinkage
/
less than 4%
Recommended application tools: Squeegee, buffer, knife, masking tape, heat gun, magnets, gloves, IRR thermometer, IRR heater Application method: Standard methods for calendared films. No overstretching and overheating and Post heating is necessary. Post-heating temperature: 110°C flat surfaces, 130°C curves, and overlaps Aftercare: PH neutral, Avoid wax or solvents
